Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
PS9634
CEL
Product No:
PS9634
Manufacturer:
Package:
8-DIP
Batch:
-
Datasheet:
Description:
OPTOISO 5KV FOR IGBT DRIVER 8DIP
Quantity:
Delivery:
Payment:
In Stock : Please Inquiry
Please send RFQ , we will respond immediately.
PS9634 - Product Information
Parameter Info
User Guide
| Mfr | CEL |
| Type | Power Transistor Driver |
| Series | - |
| Package | Tube |
| Input Type | DC |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Product Status | Obsolete |
| Approval Agency | - |
| Voltage - Supply | 5.4V ~ 15V |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Operating Temperature | -20°C ~ 80°C |
| Rise / Fall Time (Typ) | - |
| Supplier Device Package | 8-DIP |
| Current - Output / Channel | 500mA, 800mA |
| Voltage - Forward (Vf) (Typ) | 1.1 V |
| Current - DC Forward (If) (Max) | 30 mA |
| Propagation Delay tpLH / tpHL (Max) | 5µs, 5µs |
| Common Mode Transient Immunity (Min) | 1kV/µs |
